Materials and finishes
Housing: 100% recycled aluminium2
Active Band: Fluoroelastomer with soft-touch coating
Dimensions and weight
Diameter: 45 mm
Height: 12.3 mm
Weight: 36.7 g (without band)
Display
Actua 360 display
Custom 3D Corning® Gorilla® Glass 5
320 ppi AMOLED LTPO display with DCI-P3 colour
Up to 3000 nits (peak brightness)
1 nit minimum brightness (AOD)
Responsive Display (1–60 Hz)6
Always-on display
Connectivity
Bluetooth® 6.0
Wi-Fi 802.11a/b/g/n/ac/ax 2.4GHz, 5GHz
NFC
Ultra wideband4
GPS
Dual Frequency GPS: GPS, Galileo, Glonass, Beidou, QZSS
Band size
Active Band: Small and large band sizes included
• Small fits wrists 150-185 mm around
• Large fits wrists 165-215 mm around
Power (battery and charging)
455 mAh (typical)
Built-in rechargeable lithium-ion battery
Up to 40 hours with always-on display7
Up to 72 hours with Battery Saver Mode7
Quick Charge Dock
Charging speed using Quick Charge Dock
• About 15 minutes to 50%7
• About 30 minutes to 80%7
• About 60 minutes to 100%
ChipCortex-M55 co-processor
OS
Wear OS 6.0
Storage and memory
32 GB eMMC flash9
2 GB SDRAM
Sensors
Compass
Altimeter
Red and infrared sensors for oxygen saturation (SpO2) monitoring10
Multipurpose electrical sensors compatible with ECG app11
Multi-path optical heart rate sensor12
3-axis accelerometer
Gyroscope
Ambient light sensor
Electrical sensor to measure skin conductance (cEDA) for body response tracking13
Far field skin temperature sensor14
Barometer
Magnetometer
Interaction
Side button
Haptic crown
Gen 3 Premium haptics
Audio
Built-in microphone
Built-in speaker
Durability and water resistance
Custom 3D Corning® Gorilla® Glass 5
5 ATM15
IP6815
